Rain Bird LFV075 3/4" Low Flow Drip Irrigation Valve
Rain Bird LFV075 Low Flow Valve For Drip Irrigation
This is the Rain Bird LFV075 3/4" Low Flow Drip Irrigation Valve, the valve designed specifically to solve the biggest challenges in drip irrigation. If you've ever had a valve that gets stuck open or "weeps" (constantly leaks) on a drip zone, this is the solution. Standard valves are designed for high-flow sprinklers, but the LFV075 is built to operate perfectly at the low flow rates of a drip system (0.2 to 8.0 GPM).
The magic is in its unique "double-knife" diaphragm and 1/2" diameter seat. This patented design allows the valve to handle small particles, even at very low flows, without clogging or weeping. This means you get a reliable, leak-free seal every time the zone shuts off.
Features:
- Prevents Weeping: The double-knife diaphragm and specialized seat create a positive seal, eliminating the constant, costly leaks common with standard valves on drip zones.
- Handles Debris: Its design allows it to pass particles at low flow rates, making it highly resistant to clogging.
- Double-Filtered Pilot Flow: This feature provides maximum reliability by protecting the solenoid ports from debris, ensuring the valve opens and closes when it's supposed to.
- Easy Manual Operation: Features an external bleed to flush the system of dirt during installation and an internal bleed for spray-free manual operation during maintenance.
- Durable & Reliable: This valve includes all the robust features of Rain Bird's professional-grade DV valves, just optimized for low-flow applications.
The LFV075 is the professional's choice for any low-flow or Xerigation system. It ensures your drip zones operate efficiently and reliably, saving water and preventing damage. Find this and other professional-grade Rain Bird Valves in our collection.
Specs:
- Flow Range: Low Flow: 0.2 to 8 gpm
- Valve Type: Inline
- Operating Range:
- Flow: 0.20 to 8.0 gpm (0.6 to 30.0 l/m)
- Pressure: 15 to 150 psi (1.0 to 10.3 bars)
- Electrical Specifications:
- 24 VAC 50/60 Hz (cycles/sec) solenoid
- Inrush current: 0.30 (7.2 VA) at 60 Hz
- Holding current: 0.19 A (4.56 VA)
